Processor: 2.9 gigahertz Intel Core Ultra 9 Series 285H (16-core) Memory: 32GB LPDDR5X 7467 megahertz RAM, Storage: 1TB M.2 NVMe™ Solid State Drive, Display:16″ 3.2K (3200×2000) OLED Touchscreen 120Hz, Brightness: 1000 nits, Wi-Fi 7, Bluetooth
Video Card: NVIDIA GeForce RTX 5060 8GB GDDR7
Windows 11 Home x64, preinstalado.
Peso 1,99Kg. – 5MP Webcam with Microphone
Model Configurations
| PERFORMANCE | |
| Processor |
Intel® Core Ultra 9 285H, 16C (6P + 8E + 2LPE) / 16T, Max Turbo up to 5.4GHz, 24MB Intel Smart Cache
|
| AI PC Category |
AI PC |
| NPU |
Integrated Intel® AI Boost, up to 13 TOPS
|
| Graphics |
NVIDIA® GeForce RTX™ 5060 8GB GDDR7
|
| Chipset |
Intel® SoC Platform
|
| Memory |
32GB Soldered LPDDR5x-8400
|
| Memory Slots |
Memory soldered to systemboard, no slots, dual-channel
|
| Max Memory |
32GB soldered memory, not upgradable
|
| Storage |
1TB SSD M.2 2242 PCIe® 4.0×4 NVMe®
|
| Storage Slot |
Two M.2 slots • One M.2 2242 PCIe® 4.0 x4 slot • One M.2 2280 PCIe 4.0 x4 slot
|
| Max Storage Support |
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each
|
| Card Reader |
SD Card Reader
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3306 codec
|
| Speakers |
6 stereo speakers, 2W x4 (dual side woofers), 2W x2 (tweeters), optimized with Dolby Atmos®, Smart Amplifier (AMP)
|
| Microphone |
4x, Array
|
| Camera |
5.0MP + IR with E-shutter
|
| Battery |
84Wh
|
| Power Adapter |
170W Slim Tip (3-pin)
|
| DESIGN | |
| Display |
16″ 3.2K (3200×2000) OLED, 1600nits (peak) / 1000nits (typical) Glossy / Anti-fingerprint, 100% DCI-P3, 100% Adobe® RGB, 100% sRGB, 120Hz, Eyesafe®, Dolby Vision®, DisplayHDR™ 1000, AGC Dragontrail™ Glass, Touch, X-Rite®, PureSight Pro |
| Touchscreen |
OGS, 10-point Multi-touch
|
| Screen-to-Body Ratio |
90.17% AAR (active area ratio)
|
| Color Calibration |
X-Rite® Factory Color Calibration
|
| Pen |
Pen Not Supported
|
| Keyboard |
Backlit, English
|
| Touchpad |
Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 95 x 150 mm (3.75 x 5.91 inches)
|
| Dimensions (WxDxH) |
362.72 x 253.69 x 17.9 mm (14.28 x 9.99 x 0.70 inches)
|
| Weight |
Starting at 2.07 kg (4.56 lbs)
|
| Case Color |
Luna Grey
|
| Case Material |
Aluminium (Top), Aluminium (Bottom)
|
| Surface Treatment |
Aluminium Stamping (Anodized with Sandblasting)
|
| SOFTWARE | |
| Operating System |
Windows® 11 Home, English
|
| Bundled Software |
Office Trial + Lenovo® AI Now
|
| CONNECTIVITY | |
| WLAN + Bluetooth |
Wi-Fi® 7, 802.11be 2×2 + BT5.4
|
| WWAN |
WWAN Not Supported
|
| Ethernet |
No Onboard Ethernet
|
| Standard Ports |
|
| Docking |
Various docking solutions are supported via Thunderbolt™. For more compatible docking solutions, please visit Docking for Yoga Pro 9 16IAH10
|
| SECURITY & PRIVACY | |
| Security Chip |
Firmware TPM 2.0
|
| Fingerprint Reader |
None
|
| Other Security |
|
| SERVICE | |
| Included Upgrade |
None
|
| ACCESSORIES | |
| Bundled Accessories |
None
|
| CERTIFICATIONS | |
| Green Certifications |
|
| Mil-Spec Test |
MIL-STD-810H military test passed (21 test items)
|
| Other Certifications |
|
| MODEL INFORMATION | |
| Model |
83L00000US
|
| Machine Type |
83L0
|
| Region |
NA
|
| Country/Region |
USA
|
| TopSeller |
No
|
| EAN / UPC / JAN |
198155510151
|
| Announce Date |
2025-05-30
|
| End of Support |
2031-06-09
|
